Dongguan Yonghui Leather Machinery Co., Ltd.
| Model | YH-4060 |
|---|---|
| Voltage | 220V |
| Power | 450W |
| Sewing speed | 3000 s.p.m |
| Stitch length | 8.0mm |
| Height of presser foot | 6mm |
| Max thickness of sew material | 5mm |
| Needle bar stroke | 28mm |
| Needle system | DBx1 #21 (#18-#23) |
800 strobel sewing machine for shoes is suitable for sewing leather, shoes, furs with auto lubrication, high precise, high speed, efficient working performance.
Features:
1. Single needle, single thread overlock stitch
2. Perfect stitch with consistent stitch tension and spacing
3. Noticeable lack of vibration and noise ensure quiet and smooth running
4. With gravity feed oiling system reduces the oil leakage and maintenance, trouble-free and long life.
5. Needle Positioner can be fitted.
1. The stepping motor control type of front disk feeding, compared with the normal (non-driven) type of front dish feeding, much simple & easy for the sewing operation.
2. Applied with the pneumatic automatic undertrimming mechanism, the undertrimming result is more perfect and increase the sewing efficiency.
3. The max sewing speed is up to 3,000 S.P.M
4. The special disk feed, suitable for shoes-insole stitching.
